Ultra-High Power, Wide Compatibility; Liquid Cooling Technology, Safe & Efficient; Split Architecture, Flexible Deployment; All-Weather Operation, Extreme Environment Resilience; Smart Power Allocation, Dynamic Adjustment; Reduced Grid Impact, Lower Infrastructure Costs; Intelligent O&M, Cost-Effective;
| EV Charger Type | DC |
| Charger Capacity | 240-960KW |
| AC Supply System | 3-Phases, 5 Wire AC system |
| Nominal Input Voltage | AC380V±15% |
| InputFrequency | 45-65Hz |
| Ambient Temperature Range | -25 to 55°C |
| Ambient Humidity | 5 to 95% |
| IP Ratings | IP 54 |
| Cooling | Liquid Cooling |
| Number of Qutputs | 10~24 |
| Type of Each Output | DC200-1000V |
| Single Output Max. Current | 200/250 Amp |
| Display & Screen Size | 4.3 Inches Screen |
| User Authentication | QR Code |
| Liquid Cooling Current | 600A(CCS1&CCS2&GBT) |
| Communication between EVSE and Central Server | OCPP 1.6J Protocol (Optional) |
| Interface between Charger and CMS | Ethernet/3G/4G/WIFI (Optional) |
| Executive Standard | IEC 62196 2017, IEC 61851 2017, SAE J1772, GB/T 20234. |
